VuMAX HD
See Every Detail
VuMAX HD
Simply the Best.
Period.
Unparalleled in every regard: image quality, advanced tools including UBM AI alignment features, automated ICL Guru interface, sulcus-to-sulcus measurement and nomograms, automated quantitative angle analysis, and more.
Elegant, intuitive, exceptional.
Unparalleled Image Quality.
Hands down the gold standard in ophthalmic ultrasound. Unparalleled UBM and B-scan image quality with Enhanced Focus Rendering™ and large ultra high resolution screen allows you to capture both crisp still images and record video that can be carefully reviewed frame-by-frame.
Elegant user interface provides useful tools that are intuitive, simple, and efficient to use. Time-saving features such as selectable patient database display to easily search and access archive exam records. Document scan orientation with the single click of a button. Replay videos in real-time, slow motion, or frame-by-frame. Super-impose A-scan trace, perform linear and angle measurements, and annotate onto B-scan and UBM images. Auto calculation of axial length average and standard deviation, nine IOL formulas, and lens database for biometric A-scan.
Elegant.
Intuitive.
Exceptional.
PRESETS
Multiple preset scan modes with settings optimized for
areas of interest
PROBE ORIENTATION
Easy graphical selection
of scan orientation for
all modes
TOOL SET
Simple to use measurement
and annotation tools
REVIEW
Frame-by-frame, full
speed, and slow motion review of video clips
PROBE CHOICES
Choice of 35 or 50 MHz UBM transducers, 12 or 20 MHz B-probes, and/or A-probes
CONNECTIVITY
Dual-band WIFI, Ethernet, USB, and Bluetooth interface
FLEXIBILITY
Configurable as a B-scan, UBM, A-scan, or in a variety of combinations to meet the needs of your practice
BIG IMAGE
See fine details with high-resolution scans displayed on the large HD flat panel monitor
Unparalleled B-Scan.
The all-new B-scan mode of the VuMAX™ HD produces truly outstanding imaging of the posterior segment that has become the new gold standard.
SEE EXTRAORDINARY DETAIL WITH ENHANCED FOCUS RENDERING
Easily visualize extraordinary fine details within video clips and still images generated using proprietary Enhanced Focus Rendering™, providing image quality unmatched by other imaging systems.
OPTIMIZED ULTRASOUND IMAGING SETTINGS
MADE EASY
Select from 4 preset scan modes to optimize image quality in area of interest, including orbit, vitreous body, retina surface, and deep retina / choroid.
Unparalleled UBM.
The VuMAX series from Sonomed Escalon has long been the gold standard in UBM imaging. Now with Enhanced Focus Rendering™ and other enhancements, the VuMAX™ HD delivers the most outstanding UBM images and video clips of the entire anterior chamber.
GLAUCOMA MANAGEMENT
The specialized angle detail scan setting optimizes resolution of different structures at the angle and behind the iris, providing the premier diagnostic tool for identifying causes of glaucoma-related concerns, including angle detail and permeability of the trabecular meshwork, plateau iris syndrome, effects of pupil movement on the angle, and other causes of glaucoma.
ICL SIZING
The preeminent system for high-resolution UBM imaging for ICL sizing. Utilize UBM AI tools to quickly and confidently obtain well-aligned scans to ensure the most accurate measurements of sulcus-to-sulcus and other anatomical parameters. Exclusive ICL Guru interface for the most accurate predictive ICL sizing and resultant lens vault..
ANTERIOR SEGMENT
View the entire anterior segment in great detail, with optimized scan settings of the VuMAX™ HD. Clearly visualize the ciliary body, pars plana, and other structures and identify tumors, cysts, trauma, uveitis, and other pathologies. The VuMAX™ HD even allows for visualization and video capture of accommodation.
UBM AI and
ICL Guru.
Eye Tracking, Align Assist, and Auto Capture UBM AI features provide real-time image analysis and intuitive feedback for ensuring well-aligned scans and the most accurate measurements required for ICL sizing. Exclusive ICL Guru interface for the most accurate predictive ICL sizing and resultant lens vault.
Quantitative Angle Analysis.
Accurately and consistently measure key parameters of the angle using the VuMAX HD UBM angle analysis tool. Easily track structure properties over time and assess differences during mydriatic and miotic conditions.
Sulcus-to-Sulcus Probe Alignment.
Measuring sulcus-to-sulcus is required for several ICL sizing nomograms. The key to accurately measuring sulcus-to-sulcus is ensuring proper probe alignment. The VuMAX HD Eye Tracking and other UBM AI features provides real-time intuitive feedback to ensure your scans are properly aligned.
As You Like It.
B-scan. UBM. A-Scan. Any combination.
B-SCAN
Unparalleled image quality with proprietary Enhanced Focus Rendering™
12 and 20 MHz frequency transducers available for posterior B-scan
256 ray scan with 2048 sample points for each ray (over a half-million sample points per transducer sweep)
Capture configurable length video clips at up to 20 frames per second
Store unlimited images and and configurable number of video clips in each exam
Automatically populates B-Biometry parameters into preferred formulas for calculation of IOLs
UBM
Unparalleled image quality with proprietary Enhanced Focus Rendering™
35 and 50 MHz frequency transducers available for UBM
256 ray scan with 2048 sample points for each ray (over a half-million sample points per transducer sweep)
Capture configurable length video clips at up to 20 frames per second
Store unlimited images and configurable number of video clips in each exam
UBM scan cap kit compatible with ClearScan® device for direct contact UBM scanning
Advanced tools such as automated angle analysis, Eye Tracking, Align Assist, Auto Capture, and ICL Guru interface
A-SCAN
Immersion or direct contact A-scan
Manual or automatic capture (cataract, dense cataract, aphakic, silicone oil, and pseudophakic modes)
Auto calculation of axial length, anterior chamber depth, lens thickness, and vitreous, with axial length average and standard deviation provided for up to 10 scans per exam
Standard IOL formulas: Binkhorst, Regression-II, Theoretic/T, Holladay, Hoffer-Q, and Haigis
Post-refractive IOL formulas include Latkany Myopic Regression, Latkany Hyperopic, and Aramberri Double-K
